RC930
Feature
Parameter
Item unit model
Loading capacity kg 1800
Bucket capacity M3 0.8
Max.Dumping height mm 3200
Dumping distance mm 800
Total cyling time s ≤10
Max.Breakout force Kn 30
Low Speed km/h 3.5
High speed km/h 28
Min.tuming radius m 4.5
Steering angle / ±30°
Dimention L*W*H mm 5300x1860x2750
Bucket width mm 1400
Diesel engine model Yunei 4100 with torbo charge
Rated power Kw 55Kw
Working hydro.pressure Mpa 16
Tyre / 20.5-16
Braking system / air brake
Transmission type / continuously varaible transmission (auto)
Total weight kg 3500
