26m truck boom pump with mixer
Brief introduction
The 26m truck concrete pump with mixer produced by Hunan Tant heavy industry is a new type of concrete construction equipment composed of 26m truck concrete pump and 500 forced mixer. It can not only mix concrete on site, but also beat commercial concrete and mix and transport all-in-one machine. The mixer truck is a 5-SECTION boom with high safety factor and efficient construction.
Feature
Parameter
26M TRUCK BOOM PUMP SEIRES OF MAIN TECHNICAL PAREMETERS
底盘型号Chassis Model Sinotruck Howo 4x2
排放标准Emission Standard 国五 GB V
发动机 Engine Brand                     Man power 280HP
轴距Wheel Bas 4700mm
最大行驶速度 Max Speed 80km/h
分动箱品牌Transfer gear Germany STIEBEL/Zhuzhou gear
臂架系统 BOOM SYSTEM
臂架最大垂直高度
Max.vertical Reach
25.3m
布料深度
Max.deep reach
16.1m
布料半径
Max.Placing boom radius
21.9m
第一节臂长(mm)
Length of the first jib
5850mm
第二节臂长(mm)
Length of the second jib
5800mm
第三节臂长(mm)
Length of the third jib
5500mm
第四节臂长(mm)
Length of the fourth jib
2000mm
第五节臂长(mm)
Length of the fifth jib
2800
各节臂转动角度
Arm Section Articulation
89/180/180/270/90°
臂架控制模式
Boom Control Model
负载敏感的比例控制
Load sensitive proportional control
臂架折叠方式Boom Type RZ Type
转塔旋转角度Slewing Range 360°
前支腿横跨距离
Front Outriggers Spread
5200mm
后支腿横跨距离
Rear Outriggers spread
5100mm
前后支腿纵向距离
Distance of the back and forth leg
5400mm
支腿打开方式Open way of Legs X+X
尾胶管长度End Hose Length 3000mm
混凝土输送管直径(MM)Arm Attached Pipeline Diameter 125mm
电气控制系统ELECTRICAL CONTROL SYSTEM
控制电源Power Supply 24V
控制模块Control Module 进口Import
工作电压Working Voltage 24V
中间电器品牌
Relay
CR-5
无线遥控器品牌
Wireless Remote Controller
DBM 迪比蒙
液压传动系统 HYDRAULIC SYSTEM
液压系统类型
Hydraulic System Type
开式液压系统
Open Loop
系统工作压力
System Working Pressure
32.0Mpa
主液压油泵品牌
Main Hydraulic Pump Brand
韩国川崎140+60
Chuanqi in Korea 140+60
主油泵型号
Main Hydraulic Pump Type
140+60

臂架油泵 hydraulic pump for boom 德国力士乐
Germany Rexroth
吸丶回油滤芯品牌
Oil Suction and Return Filter
德尔 Der
Der
臂架多路阀品牌
Multi-Way Valve
意大利科迈
Italy Kemai
臂架平衡阀品牌
Boom Counterbalance Valve
意大利NEM
Italy NEM
支腿多路阀品牌
Multi-Way Valve
国产Domestic
安全阀品牌Relief Valve 进口Import
油缸液压密封件品牌
Cylinder Hydraulic Seal
Parker
液压油箱容积
Hydraulic Oil Tank Capacity
540L
液压油冷却方式
Hydraulic Oil Cooling
风冷
Air Cooling
主油缸Main Oil cylinder 1450mmX80mmX125mm
分动箱品牌 transfer case brand 珠齿 Zhuzhou Gear
回转减速机品牌
Turret Reduce brand
利科迈
Likomai
软管接头品牌
Hose joints brand
知名品牌Famous Brand
尺寸&重量 DIMENSIONS&WEIGHT
整车总长约(MM)
Overall Length
8600mm
整车总宽约(MM)
Overall Width
2500mm
整车总高约(MM)
Overall Height
3500mm
整车质量约(T)
Total Weigh
18000kg
泵送系统 PUMPING SYSTEM
混凝土理论排量
 Thoery output capacity
50m3/h
最大混凝土出口压力高压/低压
Max Concrete Pressure
10Mpa
混凝土分配阀形式
Concrete Valve
S阀
S Valve
系统油压
Pumping system pressure
32Mpa
混凝土活塞品牌
Concrete Piston
进口
Import
输送缸内径/行程Concrete Cylinder Bore/Stroke 230mmX1400mm
水箱容积 water tank volume 230L
输送管径 Delivery pipe dia. 125mm
最大上料高度(mm)
Hopper Charge Height
≤1450mm
料斗容积(m²)
Concrete Hopper Capacity
750L
可泵送混凝土塌落度
Concrete Slump
140--230mm
允许最大骨料尺寸(MM)
Max. aggregate dimension
碎石40/卵石50
Gravel 40mm / Pebble 50mm
润滑方式
Lubricating Mode
集中点对点润滑
Centralized and Automatic Lubrication
搅拌系统 MIXING SYSTEM
搅拌机型号 Mixer model JS500 Hydraulic lift type
出料容量 Discharge capacity 500L
进料容量 Feed capacity 800L
理论搅拌方量 Theory mixing capacity 30m3/h
